High speed stacking doors
High speed stack door is a barrier-free isolation door that can be lifted quickly. With main function of fast operation, high speed automatic stacking doors ensure clean air and dust-free for workshops. Folding stacking doors have many functions such as heat preservation, cold preservation, insect protection, wind protection, dust protection, sound insulation, fire prevention, odor prevention and lighting, etc., and are widely used in logistics channels, large-area cavities, internal windproof requirements, and external doors.
1. Technical data: |
1) Max dimension:12000mm(width)*6000mm(high) |
2) Door curtain thickness: 0.8mm |
3) Fabric material: PVC |
4) Accessories material: Nylon belt, stainless hinge, galvanized tubular shaft |
5) Door panel color: Grey, blue, yellow, red, orange, transparent, etc |
6) Guide track material: Galvanized steel |
7) Transparent window: Vision panel(square/oval) |
8) Seal performance: side |
9) Optional: safety functions, automated operation, access control |
10) Operation: servo motor |
11) Operating speed: 0.6-1.2m/sec |
12) Wind load resisitance: 50-60km/h, based on door size |
13) Sound reduction: 12dB |
14) Water pressure resistance: 2x10mmHO |
15) Rub resistance:4.9N*100 |
16) Frame resistance:self-extinguishing after 5sec from fire |
17) Operating enviroment temperature range: -30C70C |
